PRODUCT DESCRIPTION

The Champion Irrigation CL466 series automatic anti-siphon valves provide backflow protection for your water supply. The CL466 series is compact for low-profile installation and can connect to most irrigation timers.

CL466 features:
• Reliable brass anti-siphon valves with durable brass automatic actuators
• Flow control stem with external bleed screw and ¼" lead wires
• Optimal flow: 5-35 GPM
• Rated to 150 PSI (optimal is 30-90 PSI)

Solenoid: 24VAC/60hz
• Inrush current 0.59 Amps (14.2 VA)
• Holding current 0.33 Amps (7.9 VA)


Available Models:
CL466-075: 3/4", with outlet union
CL466-100: 1", with outlet union
CL466P-075: 3/4" no union
CL466P-100: 1" no union
